Fanvil X3SP Basic SIP IP Phone with PoE Support
Fanvil X3SP 是一款入門級企業級 SIP IP 電話機，支援 PoE 供電、雙網口設計、HD 音質與基本呼叫管理功能，適合小型辦公室、遠程員工或作為 PBX 系統的經濟型終端設備。
Fanvil X3SP Basic SIP IP Phone with PoE Support
這款電話機採用黑色塑膠外殼，正面設有標準數字鍵盤、導航鍵、靜音/免持/重撥鍵，以及 2 行灰階 LCD 螢幕（解析度 132x64）。背面具備雙 RJ45 網路埠（ETH + PC）、耳機插孔、聽筒接口與 DC 電源輸入孔，支援 IEEE 802.3af PoE 供電，無需額外電源適配器。
🔧 硬體規格特徵：
- ✅ Display: 2-line monochrome LCD (132x64 pixels), backlit
- ✅ Keypad: Standard numeric keypad with navigation keys
- ✅ Function Keys: 4 programmable soft keys (context-sensitive)
- ✅ Audio:
- HD Voice support (wideband audio codec G.722)
- Speakerphone with echo cancellation
- Headset port (RJ9 or 3.5mm)
- ✅ Connectivity:
- 2 x RJ45 Ethernet ports (10/100 Mbps) — ETH (PoE in) + PC (daisy-chain)
- 1 x Handset port (RJ9)
- 1 x Headset port (RJ9)
- Optional external power adapter (5V/600mA barrel jack)
- ✅ Power:
- PoE (IEEE 802.3af) compliant
- Power consumption: ~2.5W typical
- ✅ Mounting: Desktop stand (fixed) or wall-mountable (keyholes on base)
- ✅ Certifications: CE, FCC, RoHS, Made in China
- ✅ Serial & MAC:
- S/N: 1148 HF6379005306
- MAC: 0C383E1A50BC
💡 軟體與功能特性：
- 支援 SIP v2 (RFC3261), H.323, IAX2 協議
- 最多可註冊 2 個 SIP 帳戶
- 呼叫等待、轉接、保留、三方會議
- XML 應用程式支援（簡單日曆、天氣）
- LDAP 目錄查詢（需 PBX 支援）
- Web-based configuration interface (HTTP)
- Remote provisioning via DHCP Option 66 or static URL
- Firmware upgrade via web UI or TFTP
- Compatible with most SIP PBX systems:
- Asterisk / FreePBX
- 3CX
- Grandstream UCM series
- Yeastar S-Series
- Issabel, VitalPBX, etc.
